Technical Information
27
S2 Canister Vacuums
2 Function
2.1 Suction Power
Figure 030-1: Rotary Selector Switch
The suction power is set via the rotary selector switch as appropriate for the
surface to be vacuumed:
: Curtains and textiles
: Upholstery, cushions
: High-quality carpets, rugs and runners
: Energy saving, everyday vacuuming with reduced noise level
: Lightly soiled carpets and soft floors
: Hard floors, heavily soiled carpets and soft floors
For more information, see the general DTD.
3 Fault Repair
3.1 Vacuum Cleaner Cannot Be Switched On
Cause:
On/off switch faulty.
Remedy:
1. Remove the electronic; see Section 030-4.2.
2. Check the switch contacts for continuity.
3. If continuity does not exist, replace the on/off switch. See On/Off Switch
Replacement, Section 030-4.3.
Cause:
1. Faulty cord reel.
2. Faulty cord.
Remedy:
1. Remove the cord reel; see Section 010-4.3.
2. Check for voltage on the back of the cord reel (between terminals L and
