Installation and connection
63
For closets at room height
You can also insert a ventilation
opening at the top of the closet. In
addition, you must also provide an
opening on the bottom side of the
door.
Risk of damage due to
overheating of the washing machine.
The air supply must not be hindered
by an additional closet or shelf.
Please ensure that air is able to
circulate freely at the top of the
closet.
Product dimensions
Dimensions
= 1.50m drain hose with
connection to the top left on the
rear
= 2.00m electrical cord with plug
for 120V, 15A (NEMA 5-15
configuration) to the top left on
the rear
= 1.60m hot and cold-water
intake hoses to the top left on
the rear
