Introduction
Function:
1.
One or two speed positioning 7. Resolution: 0.1mm/ 0.05mm/ 0.01mm
2.
Manual / Single mode 8. Correct zero point
3.
10 sets single program 9. Display: RPM speed
4.
10 sets tool offsets 10.
Protection for tool / motor fault
5.
Quick program / Fine Adjustment 11.
Battery life 2.5 year
6.
Inch / mm conversion 12.
Self-diagnose
Specification:
1
Housing:
115w × 115h × 80d (mm)
2
Panel cut out:
93w × 67h (mm)
3
Mounting screws:
M3 × 4 104 × 104 (mm)
4
Supply voltage:
24VDC/50mA/, C type battery (1.5V) × 1
5
Battery voltage control: Low battery alarm
6
Sensor cable length: 3m
7
Thermal expansion:
α = 16 × 10
-6
× 1/K
8
Gap sensor/strip: max. 2.5mm
9
Display:
15mm LED × 6 digits × 2 line
10
Output:
4 digital output
(AC250V / 7A;DC24V/10A）
11
Input:
4 digital input（24VDC）
12
Operating elements: 20 button keyboard
13
Test mark/ interfere
.Protection class:
3 accord. to IEC 801
14
Travel Speed: 1.5m/s
15
System accuracy:
± (0.025+0.02L)mm, L: Meter）
16
Repeatability: 0.01mm
17
Temperature:
Operating temperature 0 + 50, Storage temperature –20
+70℃
18
Humidity:
max. 95% rF(Condensation not permitted）
