46
RTSP URL are as below:
Stream
URL
Main Stream
rtsp://username:password@IP:port/main
Secondary Stream
rtsp://username:password@IP:port/sub
Tertiary Stream
http://username:password@IP:port/third
Note:
1) Get the format of RTSP URL by clicking “ ”on the right side of RTSP Port.
2) Get the playback tip by clicking “ ”on the right side of Playback Port.
3) DSCP refers to the Differentiated Service Code Point; and the DSCP value is used in the IP
header to indicate the priority of the data.
4) A reboot is required for the settings to take effect.
5) The tertiary stream is only equipped on camera whose model with “-A” or “-B”.
UPnP
Universal Plug and Play (UPnP) is a networking architecture that provides compatibility among
networking equipment, software and other hardware devices. The UPnP protocol allows devices
to connect seamlessly and to simplify the implementation of networks in the home and corporate
environments. With the function enabled, you don’t need to configure the port mapping for each
port, and the camera is connected to the Wide Area Network via the router.
Table 4-4-11 Description of the buttons
Parameters
Function Introduction
Enable
Check the checkbox to enable the UPnP function
Enable Port Mapping
Check the checkbox to enable the Port Mapping
