After the calibration , the display will start a self test. Remove the load from scale
during the self test. Display will come to weighing mode automatically.
If display shows error or incorrect value, repeat the procedure again.
Linear Calibration
The linearity error caused by the performance of the weighing unit can be
corrected by “Linearity Calibration”. The digital linearization function can reduce
the linearity error. MI104 employs a 3-point linearisation.
Precise weight (1/3
rd
, 2/3
rd
and full capacity ) are needed for Linear
calibration.
 Enter the function by pressing , display will be shown
 Make sure there are no loads on the platform and wait few seconds for
STABLE display on.
 Enter the function by pressing , display will be shown
 Load the first calibration mass weight on the platform (mass weight should
be1/3 of the max capacity) and wait few seconds for STABLE display .
 Then press , display will be shown
 Load the second calibration mass weight on the platform (mass weight
should be2/3 of the max capacity) and wait few seconds for STABLE
display .
 Then press ,display will be shown
 Load the third calibration mass weight on the platform (mass weight should
be the max capacity) and wait few seconds for STABLE display .
 Then press ,display will be shown
linear
linear
Load 0
Load 1
Load 2
Load 3
pass
