Miller 22A - Parts List - Continued; Drive Roll And Wire Guide Kits (2 Drive Roll)

OM-193472 Page 31
Table 9-1. Drive Roll And Wire Guide Kits (2 Drive Roll)
. Base selection of drive rolls upon the following recommended usages:
1. V-Grooved rolls for hard wire.
2. U-Grooved rolls for soft and soft shelled cored wires.
3. U-Cogged rolls for extremely soft shelled wires (usually hard surfacing types).
4. V-Knurled rolls for hard shelled cored wires.
5. Drive roll types may be mixed to suit particular requirements (example:
V-Knurled roll in combination with U-Grooved).
Wire Diameter
Fraction Decimal Metric
.023/.025 in.
.030 in.
.035 in.
.045 in.
.052 in.
1/16 in.
.035 in.
.045 in.
.052 in.
1/16 in.
5/64 in.
.035 in.
.045 in.
.052 in.
1/16 in.
5/64 in.
.045 in.
.052 in.
1/16 in.
5/64 in.
.023/.025 in.
.030 in.
.035 in.
.045 in.
.052 in.
.062 in.
.035 in.
.045 in.
.052 in.
.062 in.
.079 in.
.035 in.
.045 in.
.052 in.
.062 in.
.079 in.
.045 in.
.052 in.
.062 in.
.079 in.
0.6 mm
0.8 mm
0.9 mm
1.2 mm
1.3 mm
1.6 mm
0.9 mm
1.2 mm
1.3 mm
1.6 mm
2.0 mm
0.9 mm
1.2 mm
1.3 mm
1.6 mm
2.0 mm
1.2 mm
1.3 mm
1.6 mm
2.0 mm
Kit No.
087131
079594
079595
079596
079597
079598
044749
079599
079600
079601
079602
079606
079607
079608
079609
079610
083318
083317
079614
079615
Drive Roll
Part No. Type
087130
053695
053700
053697
053698
053699
072000
053701
053702
053706
053704
132958
132957
132956
132955
132960
083489
083490
053708
053710
V-Grooved
V-Grooved
V-Grooved
V-Grooved
V-Grooved
V-Grooved
U-Grooved
U-Grooved
U-Grooved
U-Grooved
U-Grooved
V-Knurled
V-Knurled
V-Knurled
V-Knurled
V-Knurled
U-Cogged
U-Cogged
U-Cogged
U-Cogged
Inlet
056192
056192
056192
056193
056193
056195
056192
056193
056193
056195
056195
056192
056193
056193
056195
056195
056193
056193
056195
056195
Wire Guide
S-0157-C
.068-.072 in. .068-.072 in. 1.8 mm 089984 132959 V-Knurled 056195
.040 in. .040 in. 1.0 mm 161189 053696 V-Grooved 056192
