OM-256 476 Page 4
SECTION 2 − SPECIFICATIONS
Specification
Digital
Pro-Hobby Helmet
Digital
Performance Helmet
Digital Elite
Helmet
Viewing
Field
3.75 x 1.55 in.
(95 x 40 mm)
3.81 x 1.85 in.
(97 x 47 mm)
3.81 x 2.62 in.
(97 x 60mm)
Operating
Modes
Two Modes: Weld, Grind Three Modes: Weld,
Cut, Grind
Four Modes: Weld, Cut,
Grind, X-Mode
Reaction
Time
0.0000500 sec
(1/20,000)
0.0000500 sec
(1/20,000)
0.0000500 sec
(1/20,000)
Available
Shades
All Shades
Provide
Continuous UV
And IR Protec-
tion.
Weld Mode
Darkened State:
No. 8 − No. 13
Light State:
No. 3
Grind Mode
Light State: No. 3
Weld Mode
Darkened State:
No. 8 − No. 13
Light State: No. 3
Cut Mode
Darkened State:
No. 5 − No. 8
Light State: No. 3
Grind Mode
Light State: No. 3
Weld Mode
Darkened State:
No. 8 − No. 13
Light State: No. 3
Cut Mode
Darkened State:
No. 5 − No. 8
Light State: No. 3
Grind Mode
Light State: No. 3
X-Mode
Darkened State:
No. 8 − No. 13
Light State: No. 3
Sensitivity
Control
Adjustable For
Varying Ambi-
ent Light And
Welding/Cut-
ting Arc.
No. 10 Setting
Locks Lens In
Dark State.
Weld Mode:
No. 0 − No.10
Grind Mode:
Not Applicable
Weld Mode:
No. 0 − No. 10
Cut Mode:
No. 0 − No. 10
Grind Mode:
Not Applicable
Weld Mode:
No. 0 − No. 10
Cut Mode:
No. 0 − No. 10
Grind Mode:
Not Applicable
X-Mode:
No. 0 − No. 10
Delay
Control
Slows Lens
Dark-To-Light
State.
Weld Mode:
No. 0 − No. 10
Grind Mode:
Not Applicable
Weld Mode:
No. 0 − No. 10
Cut Mode:
No. 0 − No. 10
Grind Mode:
Not Applicable
Weld Mode:
No. 0 − No. 10
Cut Mode:
No. 0 − No. 10
Grind Mode:
Not Applicable
X-Mode
No. 0 − No. 10
Automatic
Power
Shuts Lens Off 45 Minutes After Last Arc Is Struck.
Lens automatically turns on when arc is struck.
Low Battery
Light
Red LED Illuminates To Indicate 2−3 Days Remaining Battery Life.
Power
Supply
CR2450 Lithium Batteries (Miller Part No. 217 043)
