OM-225 216 Page 15
SECTION 5 − OPERATION
5-1. Controls
1 Output Control
Use control to set cutting output.
If 22-27 amperes of cutting output is used
with 120 VAC input power, and the overload
protection on the input power circuit fre-
quently opens, either reduce the cutting out-
put and/or the cut time or find more adequate
power (see Section 4-1).
2 Power Light
3 Trouble Lights (See Section 6-6)
225 175-B
3
1
2
