A complete Parts List is available at www.MillerWelds.com
OM-246193 Page 25
6-2. Configuration Option Menu
1
2
3
4
SET -UP
Ref. 235550-A
1 Left Display
2 Right Display
3 Adjustment Control
4 Setup Button
Setup
The Configuration Option Menu provides a
means to customize some machine features
for desired operation.
To enter the Configuration Option Menu, hold
the Setup Button down during power up while
the unit is displaying 8888 on the Left and
Right Displays. SET−UP will be displayed
momentarily
.
Configuration
options are displayed in the Left
Display. Settings are displayed in the Right
Display. Settings can be changed by turning
the Adjust Control. If a setting does not
change when the Adjust Control is turned, the
option is not configurable. Pressing the Setup
Button moves to the next configuration option.
To Next Page
