Miller MSW-41 - Default Chapter; Table of Contents

TABLE OF CONTENTS
SECTION 1 − SAFETY PRECAUTIONS FOR SERVICING 1.........................................
1.1 Symbol Usage 1........................................................................
1.2 Servicing Hazards 1....................................................................
1.3 California Proposition 65 Warnings 2.......................................................
1.4 EMF Information 2......................................................................
SECTION 2 − −INTRODUCTION 3................................................................
2-1. Specifications 3........................................................................
SECTION 3 − INSTALLATION 3..................................................................
3-1. Installing Or Dressing Tips 3..............................................................
3-2. Installing Or Cleaning Tongs 5............................................................
3-3. Adjusting Tong And Hand Lever Pressure 6.................................................
3-4. Installing Handle 7......................................................................
3-5. Mounting Control Box 8..................................................................
3-6. Connecting Input Power (T Models) 8......................................................
3-7. Connecting Input Power (Non-T Models) 9..................................................
SECTION 4 − OPERATION 10....................................................................
4-1. Controls (T Models) 10...................................................................
4-2. Controls (Non-T Models) 10...............................................................
SECTION 5 − THEORY OF OPERATION 11........................................................
SECTION 6 − TROUBLESHOOTING 13............................................................
6-1. Troubleshooting Table 13.................................................................
6-2. Troubleshooting Circuit Diagram For 1.5 KVA (110 Or 220V) And 2.5 KVA
(220V) Models 15........................................................................
6-3. Troubleshooting Circuit Diagram For 1.5 KVA, 110 Volts Model 16...............................
6-4. Troubleshooting Circuit Diagram For 1.5 And 2.5 KVA, 220 Volts Models 17.......................
6-5. Waveforms For Sections 6-2, 6-3 And 6-4 18.................................................
SECTION 7 − MAINTENANCE 19.................................................................
7-1. Routine Maintenance 19..................................................................
7-2. Overload Protection For 220 Volts Model 19..................................................
SECTION 8 − ELECTRICAL DIAGRAMS 20........................................................
SECTION 9 − PARTS LIST 24.....................................................................
