2. Press the FUNCTION APPLICATION key for additional functions to appear on the display.
PARMTER CH ECK MANAGE SYS . SET MEMORY >
3. Press the F1
F1
key for the PARMTER function.
TEACH MODE
SERVO OFF
SYSTEM SWI
SELECT TYPE OF PARAMETER
BY FUNCT ION KEY
TCH WELD I / O AUTO >
4. Press the FUNCTION APPLICATION key for additional functions to appear on the display.
TEACH MODE
SERVO OFF
SENSOR AR
SELECT TYPE OF PARAMETER
BY FUNCT ION KEY
C–S TOUCH–S W–CHARA S–DATA >
5. Press F4
F4
key for the W–CHARA function to set welding characteristics.
