Miller Welding - Shock Sensor Unit Assembly and Installation

OM-169 510 Page 3
Robot Arm
Insulator
Plate
Shock Sensor Leads
Shock Sensor
Torch
Mounting
Torch Clamp
ST-800 733
Bracket
Mounting
Bracket
Clamp
Welding Gun
Body
Figure 3-3. MRH
2
Shock Sensor Unit Assembly And Installation
Shock Sensor
Torch Mounting
ST-800 778
Angle Bracket
Bracket
Torch Clamp
L-Bracket
Insulating Block
Angle Bracket
Clamp
Output Hub
Bracket
Shock Sensor
Leads
Welding Gun
Body
Figure 3-4. MRV
2
Shock Sensor Unit Assembly And Installation
