OM-236297 Page 29
Description
Part
No.
Item
No.
10-1. Consumables Flowchart
Quantity
Table 10-1. Nozzles
1 176238 Nozzle, Spot Flat (Requires Diffuser 209099, Used With Any... ......... ..
Heavy Duty FasTipt Contact Tip) 1.....................................
1 176240 Nozzle, Spot Inside Corner (Requires Diffuser 209099, Used With Any... ......... ..
Heavy Duty FasTipt Contact Tip) 1.....................................
1 176242 Nozzle, Spot Outside Corner (Requires Diffuser 209099, Used With Any... ......... ..
Heavy Duty FasTipt Contact Tip) 1.....................................
1 199610 Nozzle, Screw On Brass 1/2 In. Orifice 1... ......... .. ................................
1 199611 Nozzle, Screw On Brass 3/4 In. Orifice Straight 1... ......... .. .........................
1 199612 Nozzle, Screw On Brass 3/4 In. Orifice Straight Heavy Duty 1... ......... .. ..............
1 199613 Nozzle, Screw On Brass 5/8 In. Orifice 1... ......... .. ................................
1 199614 Nozzle, Screw On Brass 5/8 In. Orifice Heavy Duty 1... ......... .. ......................
1 199615 Nozzle, Screw On Copper 1/2 In. Orifice 1... ......... .. ...............................
1 199616 Nozzle, Screw On Copper 3/4 In. Orifice 1... ......... .. ...............................
1 199617 Nozzle, Screw On Copper 3/4 In. Orifice Heavy Duty 1... ......... .. ....................
1 198855 Nozzle, Screw On Copper 5/8 In. Orifice 1... .......... .. ...............................
1 199618 Nozzle, Screw On Copper 5/8 In. Orifice Heavy Duty 1... .......... .. ....................
1 207313 Nozzle, Screw On Copper 5/8 In. Orifice 15/16 OD 1... ......... .. ......................
1 209033 Nozzle, Slip On Copper 1/2 In. Orifice Tapered (Requires Diffuser 209031 Or ... ......... ..
209032 And Insulator 209047, Used With Any Tapered FasTipt Contact Tip) 1
1 209034 Nozzle, Slip On Copper 3/8 In. Orifice Tapered (Requires Diffuser 209031 Or ... ......... ..
209032 And Insulator 209047, Used With Any Tapered FasTipt Contact Tip) 1
1 209035 Nozzle, Screw On Copper 3/8 In. Orifice Tapered (Requires Diffuser 227 747, ... ......... ..
231 511 Or 231 512, Used With Any Tapered FasTipt Contact Tip) 1.......
1 209036 Nozzle, Screw On Copper 1/2 In. Orifice Tapered (Requires Diffuser 227 747, ... ......... ..
231 511 Or 231 512, Used With Any Tapered FasTipt Contact Tip) 1.......
Table 10-2. Heavy Duty FasTiptContact Tips*
2 206185 .030 in. (0.8 mm) 1... ......... .. ...................................................
2 206186 .035 in. (0.9 mm) 1... ......... .. ...................................................
2 206187 .040 in. (1.0 mm) or .035 in (0.9 mm) Aluminum Wire 1... ......... .. ....................
2 206188 .045 in. (1.2 mm) 1... .......... .. ...................................................
2 206189 .052 in. (1.3 mm) or 3/64 in (1.2 mm) Aluminum Wire 1... ......... .. ....................
2 206190 1/16 in. (1.6 mm) 1... .......... .. ...................................................
2 206191 .068 in. (1.7 mm) or 1/16 in (1.6 mm) Aluminum Wire 1... ......... .. ....................
Table 10-3. Extra Heavy Duty FasTiptContact Tips*
2 199605 .035 in. (0.9 mm) 1... ......... .. ...................................................
2 199606 .040 in. (1.0 mm) or .035 in (0.9 mm) Aluminum Wire 1... ......... .. ....................
2 198851 .045 in. (1.2 mm) 1... ......... .. ...................................................
2 198852 .052 in. (1.3 mm) or 3/64 in (1.2 mm) Aluminum Wire 1... ......... .. ....................
2 198853 1/16 in. (1.6 mm) 1... ......... .. ...................................................
2 198854 .068 in. (1.7 mm) or 1/16 in (1.6 mm) Aluminum Wire 1... ......... .. ....................
Table 10-4. Tapered FasTipt Contact Tips*
2 209025 .030 in. (0.8 mm) 1... ......... .. ...................................................
2 209026 .035 in. (0.9 mm) 1... ......... .. ...................................................
2 209027 .045 in. (1.2 mm) 1... ......... .. ...................................................
2 209028 3/64 in. (1.2 mm) 1... ......... .. ...................................................
2 209029 .052 in. (1.3 mm) 1... ......... .. ...................................................
2 209030 1/16 in. (1.6 mm) 1... ......... .. ...................................................
