OM-236297 Page 8
5-2.
Air-
Cooled Gun Connections
Ref. 245 995-A / 246 218-A / 250 581-A
1
Gun Control Cable
Insert
plug into Gun Control receptacle, and
tighten
threaded collar
.
2
Gun Power Pin
3
Gun Bushing
4
Gun Securing Knob
5
Drive Casting
Loosen
gun securing knob and insert gun
power
pin through gun bushing until it
bottoms
against drive casting.
T
ighten
knob.
5
4
1
Left Side
2
3
11
