Elix® 20, 35, 70 and 100 11
2-4 DESCRIPTION OF INPUT AND OUTPUT CONNECTIONS
This section describes the use of the various ports and other connection places on the front left side of the Elix System Cabinet.
PORTS
PORT DRAIN 1
The DRAIN 1 Port is used to secure the 1/2 inch OD RO Reject Tubing. This port allows RO Reject Water to exit the Elix System.
PORT FEED 2
The FEED 2 Port is used to secure the 1/2 inch OD Feedwater Tubing. This port allows Feedwater to enter the Elix System.
PORT CONC. 3
This port is used to secure the 8 mm OD Elix Module Waste Water Tubing. This port allows Elix Module Waste Water to exit the
Elix System.
PORT PRODUCT 4
The PRODUCT 4 Port is used to secure 8 mm OD Product Water Tubing. This port allows Product Water to exit the Elix System.
PORT 5
Port 5 is used when a peripheral device is connected to the Elix System. This port could be used to allow water to enter the Elix
System to the device inside.
PORT 6
Port 6 is used when a peripheral device is connected to the Elix System. This port could be used to allow water to enter the Elix
System to the device inside.
PORT 7
Port 7 is used when a peripheral device is connected to the Elix System. This port could be used to allow water to enter the Elix
System to the device inside.
TANK LEVEL AND RS 232
TANK LEVEL
A Male Stereo Jack from an Analogue Level Sensor can be plugged into the Elix System here. The Supply Voltage coming from
this connection to the Level Sensor is normally 5 VDC but can be set to 24 VDC.
RS 232
This connection allows a 9-pin Male RS 232 Cable to be plugged into the Elix System. The Transmit and Receive voltages out of
or into this connection are 5 VDC when active.
