Product Information
Elix® 20, 35, 70 and 100 12
GROMMETS
The grommets are not labelled with text on the front left side of the Elix System Cabinet. The grommet is a rubber device that
covers most of a hole drilled in the side of the cabinet.
GROMMET 1
The bottom grommet is designated as Grommet 1. The Electrical Cable going from the Elix System to the externally located Inlet
Solenoid Valve goes through this grommet. The voltage in this electrical cable is either 100, 120 or 230 VAC depending upon the
voltage supplied to the Elix System.
GROMMETS 2 THROUGH 7
These grommets are used to allow an electrical cable to go into or out of the Elix System. The electrical cable(s) are used to
control or to power peripheral devices. The voltage in any one of these electrical cables is dependent upon the device being used
and the way that the device is interfaced with the Elix System PC Board.
