Figure 27: Setup for system draining steps 1 and 2.
3. Replace retentate silicone (translucent) tubing in retentate port.
Reconnect pump outlet Sta-Pure (white) tubing.
4. Disconnect pump outlet Sta-Pure (white) tubing from FEED
IN port and place in collection vessel. Open tank outlet valve,
turn pump speed up to drain reservoir.
5. Reconnect the pump outlet Sta-Pure (white) tubing to the
FEED IN port.
RETENTATE TUBING
PUMP OUTLET
TUBING
COLLECTION
VESSEL
Figure 28: Setup for system draining steps 3–5.
