Labscale Tangential Flow Filtration System User Guide 35
RETENTATE TUBING
Figure 33: Preconditioning Setup.
Drain Permeate Tubing
1. Disconnect the permeate tubing (silicone, translucent) from
the permeate outlet (PERM 2) port. Drain permeate tubing
into the waste collection vessel.
2. Reconnect the permeate tubing to the PERM 2 port.
Concentration
1. Remove reservoir cover and fill reservoir with sample to be
concentrated.
2. Ensure vent port is open by removing plug from VENT port
and leaving open or install a Millex Filter. Open tank outlet
valve.
To Next Page
