00108103w REV 0421 8 of 10
Symptom Cause Corrective Action
Voltage reading higher than
20 mV during “Electrode
Functionality Check”
Meter is connected
to charger
Disconnect the meter from the charger.
Low battery charge Recharge battery for 12 hours.
Electrode not equilibrated Condition the electrode as outlined in “Equilibrating the Electrode”.
Dirty electrode tips Clean the electrode as outlined in “Electrode Cleaning”.
Conductive contamination
between electrodes
Inspect the inter-electrode surface areas for material which could form
a conductive bridge between the inner and outer electrodes. If the
material cannot be removed, replace the electrode.
Corrosion on electrode
conductive traces
Inspect the embedded copper circuit traces that run from the electrode
tip and up the handle. If any black discoloration is observed at the tip,
replace the electrode.
Specifications
Millicell
®
ERS-2 Meter
Membrane voltage range ± 200.0 mV
Voltage measurement 0.1 mV
Resistance range 0 to 9,999 Ω
Resistance resolution 1 Ω
AC square-wave current ± 10 µA nominal at 12.5 Hz
Power Internal 6 V NiMH 2,700 mAh battery
with external 12 V DC supply for recharging
Nominal battery run time ~ 8 hours*
Analog output Millivolt mode: 1 mV = 10 mV
Ohm mode: 1 Ω = 1 mV
Environmental range 50–100 °F (10–38 °C)
0–90% non-condensing relative humidity
Dimensions 7.25 in. (18.4 cm) × 4.25 in. (10.8 cm) × 2.3 in. (5.8 cm)
Weight 3 lb (1.4 kg)
* When the battery power level falls below a minimum threshold, the meter automatically powers off.
A fully charged battery will provide about 8 hours of running time.
Regulatory Compliance
This product is in conformity with the following standards, and therefore meets the provisions
of European LV Directive 2006/95/EC and European EMC Directive 2004/108/EC.
Safety: EN 61010-1: 2001 (Eqv: IEC 61010-1:2001)
EMC: EN 61326-1: 2006 (Eqv: IEC 61326-1:2005)
EN 61326-2-3: 2006 (Eqv: IEC 61326-2-
3:2006)
