Milltronics COMPU-M User Manual

PARAMETERS
GENERAL
(F) indicates parameters’ factory setting, where applicable
(V) indicates parameter can be viewed only.
PARAMETERS
P01 Mode Select
Defines the type of application. The Compu-M selects the appropriate Automatic Parameter Access (APA)
software routine based on the value entered.
enter: 1 = belt scale (F)
2 = flowmeter
P02 Operation
Defines the type of transducing element utilized to provide the load signal input to the Compu-M.
enter: 1 = load cell (F)
2 = LVDT
P0 Rate Units
Defines the desired Rate Display engineering units of measure.
enter: 1 = MTPH, metric tons per hour (F) 1MTPH = 1000 KG/H
2 = KG/H, kilograms per hour 1LTPH = 2240 LB/H
3 = LTPH, long tons per hour 1STPH = 2000 LB/H
4 = STPH, short tons per hour
5 = LB/H, pounds per hour
Rate, Belt Speed and Belt Length (P1,P4,and P6) parameter values are not automatically
converted if the previously entered Rate Units (P0) are changed. After altering the Rate
Units, converted values must be entered manually for each of these parameters.
P1 Rate
Defines the rate of material flow which will produce the maximum Analog mA Output of 20 mA.
enter: Design Rate from Design Data Sheet (F = 0.000)
PL-516 59
