7ML19981CJ01 MiniRanger Plus Page 45
Applications
Parameter Directions Description
Run
P999 master reset
P001 enter '1' mode of measurement = level
P002 enter '2' material = solids
P003 enter `2' measurement response = 1 m/min.
P004 enter `102'
the transducer model purchased with this
system is an XPS-10
P005 enter `1' units = metres
P006 enter `5' empty distance = 5 m
P007 enter `4.5' span = 4.5 m
P070 enter `2' fail-safe timer = 2 min
P071 enter `2' fail-safe = low
P111-1 enter `1' level alarm, relay 1
P111-2 enter `1' level alarm, relay 2
P112-1 enter `4' relay 1, on setpoint = 4 m
P112-2 enter `1' relay 2, on setpoint = 1 m
P113-1 enter `3.9'
relay 1, off setpoint = 3.9 m (nominal
value, 0.1 m deadband)
P113-2 enter `1.1'
relay 2, off setpoint = 1.1 m (nominal
value, 0.1 m deadband)
Program
P200 enter `2' mA output = 4 - 20
Run
press run to start normal operation
