7ML19981CJ01 MiniRanger Plus Page 55
Parameter Description
Parameter Description
P000 Lock
Locks out the programming 'change value' function such that the values of
P001 through P999 cannot be changed. This however does not prevent the
`select' function from use for viewing values. Programming is locked out if
the value of P000 is other than 1954.
entry:
= 1954: unlocked
≠ 1954: locked
P001 Operation
Determines the mode of measurement.
entry:
1 = level; material level referenced to empty distance (P006)
2 = space; space to material level referenced from zero span
3 = distance; distance to target referenced from the transducer face
4 = high level switch (h.I.s.)
Level (P001 = 1) Space (P001 = 2)
Distance (P001 = 3)
or
H.L.S (P001 = 4)
P002 Material
Optimizes measurement reliability for target type.
entry :
1 = liquids, fluids or flat surfaces
2 = irregular surfaces and solids
