7ML19981CJ01 MiniRanger Plus Page 47
Applications
Parameter Directions Description
Reset
P999 master reset
P001 enter `1' mode of measurement = level
P002 enter `1' material = liquids
P003 enter `2'
measurement response = 1 m / min
Note:
the associated preset fail-safe timer is
10 minutes. Override this value by
setting P070.
P004 enter `102'
the transducer model purchased with
this system is an XPS-10
P005 enter `1' units = metres
P006 enter `3.6' empty distance = 3.6 m
P007 enter `3' span = 3 m
P070 enter `.1' fail-safe timer = 6 sec (0.1 min)
P111-1 enter `3' relay 1 function = 3, pump sequencing
P111-2 enter `3' relay 2 function = 3, pump sequencing
P112-1 enter `2' relay 1, on setpoint = 2 m
P112-2 enter `1' relay 2, on setpoint = 1 m
P113-1 enter `.25'
relay 1, off setpoint = 0.25 m (nominal
value, 0.1 m deadband)
P113-2 enter `.25'
relay 2, off setpoint = 0.25 m (nominal
value, 0.1 m deadband)
Program
P802 enter `1' submergence = on
Run
press run to start normal operation
