7ML19981CJ01 MiniRanger Plus Page 49
Applications
Parameter Directions Description
Reset
P999 master reset
P001 enter `4'
mode of measurement = high level
switch
P002 enter `2' material = solids
P003 enter `2'
measurement response = 1 m/min
Note:
this is the next fastest response
rate that would satisfy the given
maximum filling rate
P004 enter `104'
the transducer model purchased
with this system is an XPS-15
P005 enter `1' units = metres
P006 enter `4'
empty distance = 4 m (nominal
value)
P007 enter `4' span = 4 m (nominal value)
P111-1 enter `1' level alarm, relay 1
P112-1 enter `1' relay 1, on setpoint = 1 m
Program
P113-1 enter `2'
relay 1, off setpoint = 2 m (nominal
value, 1 m deadband)
Run
press run to start normal operation
