Page 52 MiniRanger Plus 7ML19981CJ01
Applications
Parameter Settings
Number Description Instructions
P001 Operation Enter "1" for level.
P002 Material
No entry required (preset for
liquid).
P003
Measurement
Response
Enter "4" for (100 m/min, Failsafe
Timer = 0.1 minutes).
P004 Transducer Enter "101" for XCT-8.
P005 Units Enter "4" for feet.
P006 Empty
Enter "4.5" for 4.50 ft (3 ft
diameter plus 1.5 ft in standpipe).
P007 Span Enter "3" for 3 ft (vessel diameter).
P070 Failsafe Timer
No entry required, (preset by
P003).
P050 Tank Shape
Enter "7" for horizontal cylinder
with parabolic ends.
P051 Max Volume
Enter "117" for 117 cubic feet
(Use vessel fabricators value).
P052 Tank Dimension A
Enter "1.5" for 1.5 ft (the horizontal
length of one parabolic end).
P053 Tank Dimension L
Enter "12" for 12 ft (the horizontal
length, excluding parabolic ends).
P200 mA Range
No entry required. (preset to “2”,
for 4-20 mA output).
Now in the RUN mode, the Reading Value and mA output will represent
volume in cubic feet.
