Milltronics miniranger plus User Manual

7ML19981CJ01 MiniRanger Plus Page 9
Specifications
Transducer
Compatible models:
• ST-25 / 50 Ultrason
®
, STH and Echomax
®
models XRS-5, XKS-6, XPS-
10, XPS-15, XCT-8 and XCT-12.
• Refer to the associated transducer manual.
Cable
Transducer:
• RG-62 A/U (or equivalent), 365 m (1,200 ft) max.
• See transducer Instructions for short extensions (in grounded metal
conduit, separate from other wiring)
mA Output:
• Belden 8760, shielded / twisted pair, 18 AWG (0.75mm
2
) or equivalent
• Maximum separation 1,500 m (5,000 ft)
Synchronisation:
• Belden 8760, shielded / twisted pair, 18 AWG (0.75mm
2
) or equivalent
Relays:
• No shielded cable necessary.
Bipolar current loop (Rack & Panel Only):
• Belden 8760, shielded / twisted pair, 18 AWG (0.75mm
2
) or equivalent
• Maximum separation 1,500 m (5,000 ft)
RS-232 Link (Rack & Panel Only):
• Belden 8760, shielded / twisted pair, 18 AWG (0.75mm
2
) or equivalent
• Maximum cable length 10 m (50 ft)
RJ-11 Link (Rack & Panel Only):
• No shielded cable necessary.
• Maximum cable length 3 m (10 ft)
