Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
parts list to the illustration.
Parts List—Manual Door Components
PELLERIN MILNOR CORPORATION
Page (5 / 5)
-------------------------------------------------------------------------------------------COMPONENTS------------------------------------------------------------------------
all 1 98CMCR4819 DOOR LOCK SWITCH ASSY, 4840F CSM
all 2 09RM01212S CAPSW 12' 180DEG ROLLER SILVER
all 4 98CF25026E DOOR MTG RING GASKET=1/8", 4840F CSM
all 5 98CF25170A SHIM=HINGE BKT BOLT, 4840F CSM
all 6 98CF25159W SHIM=DOOR LATCH STRIKER, 4840F CSM
all 7 98CX489258 RUBBER BUMPER, FOOT GUARD, 4840F CSM
all 8 98CF25085A DOOR GASKET, 4840F CSM
all 9 98CF25083 DOOR GLASS GASKET, 4840F CSM
all 10 98CF25013A DOOR GLASS, 4840F CSM
all 11 98CX15028 DOOR LATCH ASSY-DIVCYLS
all 12 60B090 AIRMT S-131 1CONV.F#W013587731
all 13 98CMCR4820 DOOR HINGE BEARING, 4840F CSM
BMP150017/2015095A
Manual Door
48040F7B,F7D, F7J, F7Z (AZ)
96
