Milnor 48040F7D - Drain Valve Body with One Valve

Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
parts list to the illustration.
Parts List—Drain Valve Body with One Valve
-------------------------------------------------------------------------------------------COMPONENTS-------------------------------------------------------------------------
all 1 A14 06400 * BONNET+CYL=4"SS DIVCYL DUMP
all 2 98CF06500B DUMP VALVE ASSY, 4840F CSM
all 3 98CF15026 GASKET DUMP VALVE, 4840F CSM
1
3,A
Legend
A. Place two gaskets together.
2
Figure 1: Drain valve
Page (1 / 1)
PELLERIN MILNOR CORPORATIONPELLERIN MILNOR CORPORATION
BMP150022/2015095A
Drain Valve Body with One Valve
48040F7B, F7D, F7J, F7Z (AZ)
