Milnor 48040F7D - Air Injection Components

Page (1 / 2)
PELLERIN MILNOR CORPORATIONPELLERIN MILNOR CORPORATION
BMP150013/2015095A
Air Injection Components
48040F7B, F7D, F7J, F7Z (AZ)
1
2
D
E
F
A
B
C
A
A. Compressed air to the bearing seal coil
B. Bearing seal coil
C. Compressed air to the pressure regulator
D. Compressed air from the bearing seal coil
E. Compressed air to the bearing
F. Compressed air to the bearing pressure switch
Legend
76
