Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
parts list to the illustration.
Parts List—Water and Steam Schematic and Components
PELLERIN MILNOR CORPORATION
-------------------------------------------------------------------------------------------COMPONENTS--------------------------------------------------------------------------
all 1 98CX820631 STEAM STRAINER 1+1/4", CSM
all 2 96D0011E 1.25"NPTBRZ N/C STEAMVALANGBD
all 3 X6 20247A 3/4" NPT .5" SPARGER MACH.
all 4 96D087WE ANGBODVLV 1.5"N/C H2O BURK BRZ
all 5 96TDC2AA71 1/2"N/C2WY240V50/60C VLV(DRYVC)
all 6 98CX820820 PRESSURE REGULATOR, 3/4 28PSI
all 7 96M001 1/2X3/8" RELIEF VALVE SET31#
all 8 98CX902450 PRESSGAUGE R1/4",0-28PSI
all 9 96TCC2AA71 3/8" N/C 2WAY 240V50/60C VALVE
all 10 GVD48400 INST=SINGLE DRAIN VLV, 4840F
all 11 GVD48402 INST=DUAL DUMP VLV, 4840F
all 12 27E956K82 PUMP STDFLO 316SS 2.0HP50C
all 13 96D087WEST ANGBODVLV 1.5" N/O H20 BURK SS
all 14 96D087WESS ANGBODVLV 1.5"N/C H20 BURK SS
BMP150018/2015095A
Water and Steam Schematic and Components
48040F7B, F7D, F7J, F7Z (AZ)
Page (2 / 2)
