Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
parts list to the illustration.
Parts List—Water Inlet Components for Tilt Washers
PELLERIN MILNOR CORPORATION
-------------------------------------------------------------------------------------------COMPONENTS-------------------------------------------------------------------------
all 1 96D087WE ANGBODVLV 1.5"N/C H2O BURK BRZ=(BURKERT# 454608K)
all 2 98CX902450 PRESSGAUGE R1/4",0-28PSI
all 3 98CX820820 PRESSURE REGULATOR, 3/4 28PSI
all 4 98CX873160 FLEXIBLE HOSE ID13XOD20X44M
all 6 60E098 HOSE 1.5" WATER SUCTION HOSE
all 7 27A070 T-BOLT HOSECLAMP 1.94"-2.25"
Page (3 / 3)BMP150020/2015095A
Water Inlet Components for Tilt Washers
48040F7B, F7D (AZ)
107
