Milnor 48040F7D - Page 126

Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
parts list to the illustration.
Parts List—Pneumatic Schematic
PELLERIN MILNOR CORPORATION
Page (3 / 3)
--------------------------------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
all 1 96R301B71 1/8" AIRPILOT 3W NC 240V50/60
all 2 96R302B71 1/8" AIRPILOT 3W NO 240V50/60
all 3 98CX820820 PRESSURE REGULATOR, 3/4 28PSI
all 4 98CX902450 PRESSGAUGE R1/4",0-28PSI
all 5 96N0012P DBL.REM.VLV.3/8"4-WAY=CTR.OFF
all 6 98CX900824 MUFFLER 3/8", 4840F CSM
all 7 96TBC2BA37 1/4" N/C 2WAY 120V50/60C VALVE
all 8 98CX851324 HOSE CLAMP D13, CSM
all 10 09N082B05 PRESSW NASON CLOSE@5LB
all 11 09N082B10 PRESSW NASON CLOSE FALLING AT 9PSI
all 12 98CX900741 QUICK EXHAUST VALVE 1/4, 4840F CSM
all 13 09N082A PRESSW NASON CLOSE @ 62 LB.
all 14 98CX900822 MUFFLER 1/4", 4840F CSM
all 15 96JH100 NEEDLE VLV.ELB.1/8"#NAS2200N01
BMP150026/2018116A
Pneumatic Schematic
48040F7B,F7D, F7J, F7Z (AZ)
