Safety Supports: 48040F_ Air-tilt Washer-extractors
PELLERIN MILNOR CORPORATION
Table 1: Parts List—Safety Supports: 48040F_ Air-tilt Washer-extractors
Find the assembly for your machine and the letter shown in the "Item" column. The components for your
machine will show this letter or the word "all" in the "Used In" column. The numbers shown in the "Item"
column are those shown in the illustrations.
Used In Item Part Number Description/Nomenclature Comments
Assemblies
none
Components
all 1 W2 21822 Weldment, Safety stand, 4840F
2. How to Use the Safety Supports
Safety supports have a red color. You must keep and use safety supports for maintenance as
told in this document.
WARNING 2 : Crush Hazard—The mechanism can fall if there is a mechanical problem.
• Always install the safety supports and remove power from the machine before you do
maintenance in the machine.
• Do not hit the safety supports while you do maintenance.
• Replace damaged safety supports.
• Stow the safety supports properly.
Install the safety supports as follows:
1. Operate the Manual controls to lift the mechanism sufficiently to put the safety supports in
their positions.
2. Put each support in its position from the nearest side of the machine. Do not go across the
machine. Install the supports as shown in the figure. Use all supports.
3. Carefully operate the Manual controls to lower the mechanism until it touches the safety
supports. Immediately release the controls when the components touch.
4. Remove electrical power from the machine.
— End of BIIFLM18 —
