Pellerin Milnor Corporation
Used In Item
Part Number Description/Nomenclature Comments
Assemblies
A 98CMCR4811 BEARING ASSEMBLY — REFERENCE 4840
B 98MW4801 BEARING ASSEMBLY — REFERENCE MWF100
Components
A 1
98CMCR4830 4840F BEARING HOUSING, METRIC
B 1
98MW4810 MWF100 BEARING HOUSING
A 2
98CMCR4831 4840F MAIN SHAFT, METRIC
B 2 98MW4811 MWF100 MAIN SHAFT
3 15K032MS BUTSOKCAP SCR M6*20 SS
4 15U137 FLTWSHR M6-1 18-8 SS
5 153E232 SQMACHKEY 3/8X3/8X3+3/4
6 15N102MS FLATMACSCR M5X10 SS
7
02 21817 SLINGER=BRG FRNT SEAL,4840F
A 8 60C160DB ORING 6.25ID3/16CS BUNA70 -362
A 8 60C160DV ORING 6.25ID3/16CS VITON70#362 VITON
A 9 60C275 ORING 10.5ID 1/8CS BUN70-275
A 9 60C275V ORING 10.5ID 1/8CS VITON-#275 VITON
B 9 60C173A ORING 8.484ID .139CS BUN70
A 10 24S148 SEAL 7.0X8.5X.625#07009304LUPN
A 10 24S148V SEAL 7.0X8.5X.625#07009304LUPV VITON
B 10 24S140 SEAL 5.75”x7.0”x.625”LUP
A 11A 54A986 TAPEROLBRG SKF#32230J2 SET
B 11B 98CX830136 TAPEROLBRG NTN 4T- HH224346/HH224310
A 12A 54A987 TAPEROLBRG SKF#32226J2 SET
B 12B
54AT101190 TIMK HH221449/HH221410=4"BORE
A 13A
X2 21802 SHAFT SEAL SLEEVE, 4840F7
B 13B
98MW90405 SHAFT SEAL SLEEVE, MWF100
A 14A
X2 21803 MACH=FRONT SEAL HLDR, 4840F7
B 14B
98MW90403 MACH=FRONT SEAL HLDR, MWF100
A 15A
X2 21804 PLATE=EXCLUDER SEAL, 4840F7
B 15B
98MW90409 PLATE=EXCLUDER SEAL, MWF100
A 16A
02 21805 REAR SEAL HOLDER, 4840F7
B 16B
98MW90404 REAR SEAL HOLDER, MWF100
A 17A
02 21806 FRONT GREASE SHIELD, 4840F7
B 17B
98MW90407 FRONT GREASE SHIELD, MWF100
A 18A
02 21807 REAR GREASE SHIELD, 4840F7
B 18B
98MW90408 REAR GREASE SHIELD, MWF100
A 19A
02 21810 GASKET=FRNT SEAL HLDR,4840F7
B 19B
98MW90406 GASKET=FRNT SEAL HLDR, MWF100
A 20A
02 21811 GASKET=REAR SEAL HLDR,4840F7
B 20B
98MW90411 GASKET=REAR SEAL HLDR, MWF100
A 21
02 21812 GASKET=EXCLUDER SEAL, 4840F7
B 21 98MW90406
GASKET=FRNT SEAL HLDR, MWF100
A 22 24S146 SEAL 7.0X8.0X.437 TYPE SSW NIT
A 22 24S146V SEAL 7.0X8.0X.437 TYPE SSW VIT VITON
B 22 24S141
SEAL EXCLUDER 10817 H1L5 SSW STYLE 5.75" X
7.875" X .625"
A 23A 24S114 SEAL 4.5X5.5X.50 JM# 9170 LUP
A 23C 24S114V SEAL 4.5X5.5X.50 JM#9170LUP-V VITON
Bearing Assembly MWF100, 4840F
5 of 6
