Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
parts list to the illustration.
Parts List—Air Tilt
PELLERIN MILNOR CORPORATION
Page (3 / 3)
--------------------------------------------------------------------------------------------COMPONENTS-----------------------------------------------------------------------
all 1 09RPS12AAS PROXSW QD CONN 12M NO-AC SHLD
all 2 98CMCR4818 RESTPAD, 4840F CSM
all 3 60B132 AIRMT S-333 3CONV F#W013587842
all 4 98CMCR4814 AIR VLVS ASSY C-BLK TLT, 4840F CSM
all 5 98CMCR4816 3/4 HOSE ASSY 24.5L, 4840F TILT CSM
all 6 98CMCR4817 3/4 HOSE ASSY 80L, 4840F TILT CSM
all 7 98CX873160 FLEXIBLE HOSE ID13XOD20X44M
BMP150016/2015095A
Air Tilt
48040F7B, F7D (AZ)
90
