— 2.15 —
Crease plate (for unit C of RC head)
The crease plate is a cutter used for the unit C of the RC head.
Adjust the plate height before using the crease plate.
1 Loosen the screw with hex hole to ad-
just the plate height.
Tighten the fixing screw with a driver to
fix the plate after adjusting the plate
height.
Fixing screw with hex hole
Plate
