MIMAKI CJV150 series User Manual

© 2014 MIMAKI ENGINEERING CO.,LTD. 3.1.1 P.1
1
2
3
4
Service Documents > Basic Specification > Main Unit Specification > Main Unit Specification (for 150 series)
Model CJV150 Issued 2014.09.15 Revised F/W ver Remark
1.0
Rev.
R.1.0
3.1.1 Main Unit Specification (for 150 series)
 Specifications
Item
Specification
Remarks
CJV150-75 CJV150-107 CJV150-130 CJV150-160
Head On-demand piezzo head IA5540
(8 nozzle line/1 head, 180 nozzle/1 nozzle line, nozzle pitch 180dpi)
Drop size;
WF3 : Small:4pl, Middle:16pl, Large:23pl
WF4 : Small:4pl, Middle:16pl, Large:35pl
Printing resolution 360, 540, 720, 1440dpi Variable dot support
Printing speed In case of 4-color is used
Print mode
(Scan x Feed)
360 x 360dpi VD :
540 x 360dpi VD :
540 x 720dpi VD :
720 x 1080dpi VD :
720 x 1440dpi VD :
1440 x 1440dpi :
Ink 4-color set installed M, C, Y, K (SS21) / M, Bl, Y, K or DK (Sb53*1) Total 8 cartridges with IC chip
installed
*1:Std model; Available by a
parameter change
*2:Not available for aq model
6-color set installed M, Bl, Y, K or DK, Lm, Lbl (Sb53*1)
8-color set installed M, C, Y, K, Lm, Lc, Or, Lk (SS21*2)
6-color +W set
installed
M, C, Y, K, Lm, Lc, W, W (SS21*2)
6-color +W ･ Si set
installed
M, C, Y, K, Lm, Lc, W, Si (SS21*2)
Ink supply For 4-color and 6-color M, Bl only, the supply is toggled switched by
installing 2 cartridges (cartridge can be replaced during printing)
The ink end uses cartridge end plate detection
Ink capacity 4-color set installed
M and Bl in 6-color
set installed
Two 440-cc cartridges for each color, that is 880 cc for each color
Except above set
installed
One 440-cc cartridges for M,C,Y,K,Lm,Lc,Or,Lk,Lbl,Dk
each color, that is 440 cc for each color
One 220-cc cartridges for W,Si each color, that is 220 cc for each
color
Media that can be used
Label media (paper-based), PV sheet (including laminated, no
more than 0.25 mm thick), fluorescent sheet, reflective sheet
(except high-brightness reflective sheet), thermal transfer rubber
sheet
Maximum printing width
800 mm
1090 mm
1361 mm
1610 mm
When the minimum right and left
non-printing areas are set
Media specs Maximum width 810 mm
1100 mm
1371 mm
1620 mm
Minimum width 210 mm
Thickness 1.0 mm or less
Roll O. D. Paper media:  mm or less
Other media:  mm or less
Roll weight 40 kg or less
Paper sleeve I. D. 2 inches or 3 inches (only 3 inches for fast speed mode)
Printing surface Side facing outward
Take-up processing Roll end fixed with adhesive tape or weak glue
Print margin Roll Left/Right:15 mm (default value)
Front: 120 mm
Back: 150 mm
Tolerance excluding media inclined
pass is
± 2mm
The left and right margins can be
changed
Minimum 5mm
Cut sheet Left/Right:15 mm (default value)
Front: 120 mm
Back: 150 mm
Origin position matching
(LED pointer)
Positioning by the LED pointer mounted on the head actuator
• Pointer is used when printing origin is changed from default
value
