4. Consumable Item Replacement
21
11
Mount a new cloth wiper.
12
Close the cloth wiper cover and the front cover, then press the [ENTER] key.
• The remaining amount of cloth wiper is reset.
Cap Replacement
If print defects (e.g., nozzle clogging, deflection) remain unresolved even after cleaning, replace with a new
cap.
• Be sure to replace the cap if you observe any scratches or other damage on the rim.
• We recommend replacing the cap every six to twelve months.
1
On the LOCAL mode screen, select [MENU] > [Maintenance], then press the [ENTER] key.
• The Maintenance menu is displayed.
2
Select [Station Maint.] > [Carriage Out] > [Move To Platen Right End], then press the [ENTER]
key.
• The carriage moves over the platen.
3
Open the front cover.
4
Remove the cap.
• Squeeze the lugs on either side of the cap and pull off.
To Next Page
