4. Consumable Item Replacement
29
2
Select [Station Maint.] > [Carriage Out] > [Move To Platen Right End], then press the [ENTER]
key.
• The carriage moves over the platen.
3
Open the front cover.
• The carriage can be moved by hand. Move the carriage slowly to a position allowing easy
access while working.
4
Replace the media cutter.
(1) Unscrew the cutter screw.
(2) Remove the cutter.
(3) Mount a new cutter.
(4) Tighten the screw to clamp the cutter.
5
Once replacement is complete, close the cover, then press the [ENTER] key.
• When disposing of the product, contact an industrial waste disposal operator or dispose of the
product in accordance with the local laws and regulations.
XY Slitter Y Cutter Replacement (JV/CJV)
Replace cutters when blades are chipped or blunt.
• Avoid touching the cutter blade. Failure to do so may result in injury.
• Avoid storing this product in locations accessible to children.
To Next Page
