Maintenance Manual > Operating Principle > Basic Operation > Initial Machine Operation
Model CJV30/TPC Issued 2008.08.04 Revised 2008.09.17 F/W ver. 1.20 Remark
1.1
1.1.3 Initial Machine Operation
Indication on LCD
Processing sequence
Step Processing Description
Indication
on LCD
1 Detection of a station origin 1. Drive the wiper motor to detect the station origin.
• When it cannot be detected, [ERROR46 WIPER] is displayed and
the system goes down.
• If an error occurs during the service mode, try the operation again
by pressing the key [ENTER]. Pressing the key [FUNCTION] is
also workable.
2 Detection of the Y origin. 1. Drive the Y-axis motor to detect the Y origin.
• When it cannot be detected, [ERROR51 Y-ORIGIN] is displayed
and the system goes down.
3 Capping 1. Move the head carriage back to the Y origin and carry out capping.
4 Correcting the Y-axis distance
(Only when MAIN power is on)
1. Make the print head carriage go and return one time by a platen width,
correct the Y-axis distance, and conduct the linear encoder test.
• In the malfunction, [ERROR08 LinearENCODER] is displayed and
the system goes down.
5 Stand by of cut head • Move the cut head to the maintenance position at the left of the unit
and check the coupling of the cut head.
(Refer to “
1.1.6 Operation for Connecting the Heads
”)
A display at the start of the operation
PLEASE WAIT
