Maintenance Manual > Operating Principle > Maintenance Function > NOZZLE WASH
Model CJV30/TPC Issued 2008.08.04 Revised 2008.09.17 F/W ver. 1.20 Remark
1.1
1.2.3 NOZZLE WASH
Indication on LCD
Processing sequence
Step Processing Description
Indication
on LCD
1 Start 1. Taking the cap off.
2. After moving the print head carriage to the maintenance location, the wiper
moves to the wiping location and the servo motor is turned off.
3. Locking the pump tube.
2 Maintenance (Wiper) 1. The unit does not operate during maintenance.
2. Waiting for the end of maintenance is displayed. (Waiting for [ENTER] input)
3 Maintenance
(Nozzle wash)
1. Turning the wiper off
2. Lock the pump tube and display the message. (Waiting for [ENTER] input)
3. Input the waiting time. (Waiting for [ENTER] input)
Setting value: 1 - 99 min. (unit: 1 min.)
4. After moving the print head carriage and performing “Initial machine operation
(1.1.3)”, wait for the set time to elapse.
Press [FUNCTION], and the maintenance washing liquid will be injected into
the cap.
4 End 1. Executing cleaning
2. End
Out of “Service mode”, a warning beep sounds at an interval of 30 seconds during carriage out operation to
prevent the nozzle surface and the inside of the cap from getting dry.
Display during maintenance
WIPER CLEANING
COMPLETED(NEXT) :ent
Display during maintenance
Fill the liqid.
COMPLETED(NEXT) :ent
Display during maintenance
ST.MAINTENANCE
LEAVING TIME : 1min
Display during initial operation
PLEASE WAIT
