MIMAKI JV5 Series Maintenance Manual

© 2009 MIMAKI ENGINEERING CO.,LTD.
1.3.4 P.1
1
2
3
4
5
6
7
8
R.1.1
Maintenance Manual > Operating Principle > Ink System > Cartridge LED Control
Model CJV30/TPC Issued 2008.08.04 Revised 2010.11.05 F/W ver. 2.50 Remark
1.1
Rev.
1.3.4 Cartridge LED Control
 Condition of each cartridge LED indicated by its lighting and blinking
The two LEDs light up or blink to indicate the condition of the cartridge and help the user determine the time for replacing
the cartridge.
*1 Ink IC: NON-ORIGINAL INK, WRONG INK IC, Kind of INK, Color of INK, WRONG CARTRIDGE,
Expiration:2MONTH
 LED operation pattern
LED Cartridge status
Control LED
(Green)
Not lit No cartridge has been selected as the supply cartridge
Blinking –
Lit  A cartridge has been selected as the supply cartridge
(All cartridge LEDs are Lit for any other than the 4-color ink set except when an error occurs.)
 Ink use-up cleaning is now being performed
For details, see "1.3.7 Use-up Cleaning".
Error LED (Red) Not lit The cartridge is normal
Blinking An error has occurred (Blinking signifies that one of the following errors has occurred)
 Cartridge near end
 Cartridge ink end
 One month has passed since the expiration date of the ink
Lit An error has occurred (Lighting signifies that one of the following errors has occurred)
 Residual quantity 0 cartridge
 No cartridge
 Ink IC*
1
 REINSERT CARTRIDGE
Event
For the 4-color ink set
Except for the
4-color ink set
Cartridge 1 Cartridge 2 Cartridge 1
Control LED Error LED Control LED Error LED Control LED Error LED
Online supply start
 Both cartridges free from problems
 Cartridge 1 is the control cartridge.
Lit – – – Lit –
Cartridge 1
 Cartridge near end
Lit Blink – – Lit Blink
Cartridge 1
 Cartridge ink end
 Cartridge 2 is the control cartridge.
–BlinkLit – –Blink
Cartridge 2
 Cartridge near end
– Blink Lit Blink
Cartridge 1
 Removed for replacement
–LitLitBlink–Lit
Cartridge 1
 A normal cartridge has been set
– – Lit Blink Lit –
Cartridge 2
 Cartridge ink end
 Cartridge 1 is the control cartridge.
Lit – – Blink
Online printing has been completed
 All valves closed
Lit – – Blink Lit –
