4 Technical data
4.1 Cameras
4.1.1 Pan and tilt
Dimensions
Diameter
Cylindrical length
sapphire glass
50mm
32mm
3.5mm
Picture sensor
1/3“ Color CMOS
Resolution
PAL
NTSC
520 TV-lines
500 TV-lines
Photosensitivity
0.02Lux@F1.2
Focus
Auto mechanical
Zoom
2-way electric
Lens
Wide-angle lens
Aperture angle 106° diagonal
Illumination
Adjustable
LEDs
Swivel range
-5° to 95°
Endless rotation
Locating
Multi frequency
Locating transmitter
512Hz, 640Hz and 33kHz
Pressure tight
6 bar water tight
Operating temperature
-10°C to 60°
Table 4.1: technical data pan and tilt camera head
4.2 Reel
Made from stainless steel and carbon with standard 40m/6.7mm push rod control
unit with
• On/Off switch
• Light regulation
• BNC video-out
