A - 12
*Measurement accuracy verification: In adult and pediatric modes, the blood pressure measurements measured
with this device are in compliance with the Standard for Non-invasive sphygmomanometers (ISO 81060-2)in
terms of mean error and stardard deviation by comparing with intra-arterial or auscultatory measurements
(depending on the configuration) in a typical patient population. For auscultatory reference, the 5th Korotkoff
sound was used to determine the diastolic pressure.
In neonatal mode, the blood pressure measurements measured with this device are in compliance with the
American National Standard for Non-invasive sphygmomanometers (ISO 81060-2) in terms of mean error and
stardard deviation by comparing with intra-arterial measurements (depending on the configuration) in a typical
patient population.
A.5.8 IBP Specifications
Static pressure measurement accuracy ±3mmHg
Maximum measurement time Adult, Pediatric:
Neonate:
180s
90s
Initial cuff inflation pressure range Adult:
Pediatric:
Neonate:
80 to 280 mmHg
80 to 210 mmHg
60 to 140 mmHg
Default Initial cuff inflation pressure Adult:
Pediatric:
Neonate:
160 mmHg
140 mmHg
90 mmHg
Measurement range Adult Pediatric Neonate
Systolic mmHg 25 to 290 25 to 240 25 to 140
Diastolic mmHg 10 to 250 10 to 200 10 to 115
Mean mmHg 15 to 260 15 to 215 15 to 125
Software overpressure protection Adult: 297±3 mmHg
Pediatric: 297±3 mmHg
Neonate: 147±3 mmHg
Measurement accuracy* Max mean error: ±5 mmHg
Max standard deviation: 8 mmHg
Resolution 1 mmHg
Standard Meet the standard of IEC 60601-2-34
Channels 2
Zero adjustment range ±200 mmHg
Resolution 1 mmHg
Sensitivity 5 V/V/mmHg
Measurement range -50 mmHg to 360mmHg
Accuracy ±2% or ±1mmHg, whichever is greater
(without considering transducer error)
IBP sensor temperature range Operation temperature: 15 to 40ºC
Storage temperature: -25 to 70ºC
Wa v e f o r m l a b e l A r t, Ao, FA P, B A P, U A P, PA , C V P, U V P, L A P, R A P, I C P, P 1 , P 2 , e t c
