A - 8
A.5.2 ECG Specifications (from Defibrillation Electrodes)
Patient connection paddles or multifunction electrode pads
ECG inputs pads/paddles
Gain 2.5 mm/mV (×0.25), 5 mm/mV (×0.5), 10 mm/mV (×1), 20 mm/mV (×2),
40mm/mV (×4), Auto. Error less than ± 5%
Sweep speed 6.25mm/s, 12.5 mm/s, 25 mm/s, 50 mm/s. Error no more than ± 5%
Bandwidth (-3dB) Therapy mode: 1 to 20 Hz
Common mode rejection Therapy mode: >105 dB
Notch filter 50/60Hz
In Therapy mode: notch filter turns on automatically
ECG signal range ±8mV (peak-to-peak value)
Calibration signal 1mV (peak-to-peak value) ±5%
Differential input impedance ≥5 M
Electrode offset potential tolerance ±1V
Defibrillation protection Enduring 5000V (360 J) charge without data loss or corruption
Baseline recovery time: <2.5 s (after defibrillation)
Polarization recovery time: <10 s
Defibrillation energy absorption: ≤10% (100 load)
ESU protection Cut mode:
Coagulate mode:
Recovery time:
300 W
100 W
≤10 s
In compliance with the requirements in clause 202.6.2.101 of IEC 60601-2-27
Pace Pulse
Pace pulse markers Pace pulses meeting the following conditions are labelled with a PACE
marker:
Amplitude:
Width:
Rise time:
±2 to ± 700 mV
0.1 to 2 ms
10 to 100 µs
Pace pulse rejection When tested in accordance with the IEC 60601-2-27: 201.12.1.101.13, the
heart rate meter rejects all pulses meeting the following conditions.
Amplitude:
Width:
Rise time:
±2 to ± 700 mV
0.1 to 2 ms
10 to 100 µs
HR
Measurement range Pediatric:
Adult:
15 to 350 bpm
15 to 300 bpm
Accuracy ±1% or ±1bpm, which ever is greater
Resolution 1 bpm
Sensitivity 200 V
Heart rate averaging In compliance with the requirements in Clause 201.7.9.2.9.101 b) 3) of IEC
60601-2-27, the following method is used:
If the last 3 consecutive RR intervals are greater than 1200 ms, the 4 most
recent RR intervals are averaged to compute the HR. Otherwise, heart rate is
computed by subtracting the maximum and minimum ones from the most
recent 12 RR intervals and then averaging them.
The HR value displayed on the screen is updated every second.
