3-28
6. Select [Main Menu]→[Maintenance >>]→[User Maintenance >>]→ [Cal. IBP
Press. >>]. In the [Cal. IBP Press.] menu, set the calibration pressure to 200 mmHg.
7. Select the [Calibrate] button next to the desired IBP channel to start a calibration.
If the calibration is completed successfully, the message [Calibration Completed!] will be
displayed. Otherwise, a corresponding message will be displayed.
Method 2
Tools required:
Standard sphygmomanometer
Balloon pump
Tubing
T-shape connector
To perform a calibration:
1. Connect the 3-way stopcock, the sphygmomanometer and the balloon pump through a
T-shape connector, as shown below.
2. Vent the transducer to the atmospheric pressure by turning on the 3-way stopcock to the
air. Zero the transducer, and then open the stopcock to the sphygmomanometer.
3. Select [Main Menu]→[Maintenance >>]→ [User Maintenance >>]→enter the
required password→ [Cal. IBP Press. >>]. In the [Cal. IBP Press.] menu, set the
calibration pressure to 200 mmHg.
4. Inflate using the balloon pump until the reading of sphygmomanometer approximates
the preset calibration value.
5. Adjust the calibration value in the [Maintain IBP] menu until it is equal to the reading
of sphygmomanometer
6. In the [Cal. IBP Press.] menu, select the [Calibrate] button next to the desired IBP
channel to start a calibration
Sphygmomanometer
T-shape connector
3-way stopcock
Pressure transducer
Pressure adapter cable
IBP Module
