To initiate auto alarm limits, follow this procedure:
1. Access the Limits page in either of the following WAYS:
◆ Select the Alarm Setup quick key → select the Limits tab.
◆ Select the Main Menu quick key → from the Alarm column select Limits.
2. From the Limits page, select Auto Limits at the left bottom.
3. Select Ok from the popup dialog box.
Then the monitor will automatically calculate alarm limits basing on the latest measured values. Before applying
these automatically created alarm limits, confirm if they are appropriate for your patient from the Limits menu. If
not, you can adjust them manually. These alarm limits will remain unchanged until you select auto limits again or
adjust them manually.
The monitor calculates auto limits basing on the following rules:
Module Parameter Lower Limit Upper Limit Auto Limit Range
Adult/
pediatric
Neonate Adult/
pediatric
Neonate
ECG HR/PR
(bpm)
HR × 0.8 or 40
(whichever is
greater)
(HR - 30) or 90
(whichever is
greater)
HR × 1.25 or
240
(whichever is
smaller)
(HR + 40) or
200
(whichever is
smaller)
Adult/pediatric: 35 to 240
Neonate: 55 to 225
Resp RR (rpm) RR × 0.5 or 6
(whichever is
greater)
(RR - 10) or 30
(whichever is
greater)
(RR × 1.5) or
30 (whichever
is smaller)
(RR + 25) or
85 (whichever
is smaller)
Adult/pediatric: 6 to 55
Neonate: 10 to 90
SpO
2
SpO
2
(%) Same as the
default alarm
limit
Same as the
default alarm
limit
Same as the
default alarm
limit
Same as the
default alarm
limit
Same as the
measurement range
NIBP NIBP-S
(mmHg)
(SYS × 0.68 +
10)
(SYS - 15) or
45 (whichever
is greater)
(SYS × 0.86 +
38)
(SYS + 15) or
105
(whichever is
smaller)
Adult: 45 to 270
Pediatric: 45 to 185
Neonate: 35 to 115
NIBP-D
(mmHg)
(Dia × 0.68 +
6)
(Dia - 15) or
20 (whichever
is greater)
(Dia × 0.86 +
32)
(Dia + 15) or
80 (whichever
is smaller)
Adult: 25 to 225
Pediatric: 25 to 150
Neonate: 20 to 90
NIBP-M
(mmHg)
(Mean × 0.68
+ 8)
(Mean - 15) or
35 (whichever
is greater)
(Mean × 0.86
+ 35)
(Mean + 15 or
95)
(whichever is
smaller)
Adult: 30 to 245
Pediatric: 30 to 180
Neonate: 25 to105
Temp
(xx refers
to
temperat
ure site)
Txx (°C) (Txx - 0.5) (Txx - 0.5) (Txx + 0.5) (Txx + 0.5) 1 to 49
TD (°C) Same as the
default alarm
limit
Same as the
default alarm
limit
Same as the
default alarm
limit
Same as the
default alarm
limit
Same as the
measurement range
TempIF T (°C) (T - 0.5) (T - 0.5) (T + 0.5) (T + 0.5) 33.6 to 41.4
IBP: ART/
Ao/UAP/
BAP/FAP/
LV/P1-P4
(Arterial
pressure)
IBP-S
(mmHg)
SYS × 0.68 +
10
(SYS - 15) or
45 (whichever
is greater)
SYS × 0.86 +
38
(SYS + 15) or
105
(whichever is
smaller)
Adult: 45 to 270
Pediatric: 45 to 185
Neonate: 35 to 115
IBP-D
(mmHg
(Dia × 0.68 +
6)
(Dia - 15) or
20 (whichever
is greater)
(Dia × 0.86 +
32)
(Dia + 15) or
80 (whichever
is smaller)
Adult: 25 to 225
Pediatric: 25 to 150
Neonate: 20 to 90
IBP-M
(mmHg)
Mean × 0.68 +
8
(Mean - 15) or
35
(whichever is
greater)
Mean × 0.86 +
35
(Mean + 15)
or 95
(whichever is
smaller)
Adult: 30 to 245
Pediatric: 30 to180
Neonate: 25 to 105
