Mindray BS-180 - Major Components and Their Functions

5 Fluid System
5-3
Figure 5-2 Schematic Diagram of Fluid System
5.4 Major Components and Their Functions
Table 5-1 Major Components List
NO. Name Material code Model Quantity Remarks
1 Check valve M6Y-020003 AP19DB0012SN 2 1/8’’
2
Deionized water
tank
BA31-10-56791
Quadrate plastic tank, 10
liter, white, no cap
1
To hold
deionized
water
3 Waste tank BA31-10-56791
Quadrate plastic tank, 10
liter, white, no cap
1 To hold waste
