8-20 8 Test and Maintenance Software
NOTE
During the test, the software will configure the gain parameters of
the reaction unit. Therefore, enable the parameter modification
function of the reaction disk before testing.
NOTE
Run background test after configuration to confirm the
configuration. The recommended range for background is
48000-62000.
CAUTION
It is only necessary to run gain test after replacing the lamp and the
background overflows (exceeding 65535). Do not adjust the gain to
elevate the background.
Otherwise the performance will be affected.
Figure 8-17 Gain Test
8.5.3 Light Source Background
Run background test when it is necessary to confirm the intensity of the light source or to
confirm the gain configuration.
