Image Optimization 5-45
MPR Only
Tap on the touch screen to display MPR only. The adjustable image parameters
are changed to MPR parameters automatically.
Only A, B and C MPR are displayed, and VR is not displayed.
The MPR Only function is available in image acquisition status.
Asymmetric
Tap on the touch screen to display MPR along with VR. A larger VR image along
with 3 small MPR images will be displayed.
View Direction
The Region of Interest (ROI), also referred to as the Render Box in rendering, contains
the section of the volume you want to render. Therefore, objects that are not inside the
box are not included in the render process and are cut out (this is important in surface
mode to allow a free line of sight). This may or may not be the entire VOI.
You can adjust the view direction of the ROI.
a b
Sectional A
Sectional B
Sectional C
